10 minutes maximum An IB Periodic Table and data booklet is required. |
||||||||||||||||||||||
| 1. In an experiment to determine the empirical formula of magnesium oxide, a piece of magnesium ribbon of mass 0.50 ± 0.01 g was heated in a crucible to form magnesium oxide. The mass of the product was measured and the percentage composition of magnesium and oxygen in the final product was then calculated. What is the best way to reduce the systematic error in this experiment? | ||||||||||||||||||||||
| ||||||||||||||||||||||
2. In an experiment to measure the enthalpy change of combustion of |
![]() |
|||||||||||||||||||||
|
||||||||||||||||||||||
3. An experiment was set up to measure the potential difference of a voltaic cell, as shown in the diagram below, with a zinc half-cell and a copper half-cell.
The literature value for the potential difference is 1.10V under standard conditions. The experiment was repeated 3 times using new strips of metals each time and potential differences measured was 1.37V, 1.39V and 1.38V. How would you describe the accuracy and precision of these results? |
||||||||||||||||||||||
| ||||||||||||||||||||||
4. The literature value of the enthalpy change of the reaction 2KHCO3(s) → K2CO3(s)+H2O(l)+CO2(g) is +70.0 kJ mol-1. The experimentally measured value is +45.7 kJ mol-1. What is the percentage error in this experiment?
| ||||||||||||||||||||||
5. In an experiment to measure the enthalpy change of solution of sodium chloride, as shown in the diagram, which of the following statements about errors is correct?
|
![]() |
|||||||||||||||||||||
| ||||||||||||||||||||||
| 6. An investigation is carried out in order to study the effect of concentration of the reactant on the rate of hydrogen peroxide decomposition:
2H2O2(aq) → 2H2O(l) + O2(g) Which of the following is correct about the variables in this experiment? |
||||||||||||||||||||||
| ||||||||||||||||||||||
Questions 7-9 are about a titration experiment, in which a standard solution of sodium hydrogen carbonate NaHCO3(aq) was used to find the concentration of an unknown hydrochloric acid HCl(aq) solution. The set-up is shown in the diagram and methyl orange was used as an indicator. A rough trial was carried out at the beginning and then three titrations were done carefully, adding the acid solution dropwise near the end point. The raw data are shown in the table below.
The smallest division on the 50cm3 burette is 0.1 cm3. |
![]() |
|||||||||||||||||||||
7. What is the percentage uncertainty in the titre from trial 2?
| ||||||||||||||||||||||
8. Trials 1-3 produced concordant titre results and they were used to calculate the mean titre of the acid solution. Select the correct mean titre with its absolute uncertainty.
| ||||||||||||||||||||||
9. The concentration of the sodium hydrogencarbonate standard solution NaHCO3(aq) was 0.096 mol dm-3, and its volume was measured using a 25.00 ± 0.06 cm3 pipette. When calculating the concentration of the acid solution HCl(aq), how should its uncertainties be calculated? |
||||||||||||||||||||||
| ||||||||||||||||||||||
| 10. Which of the following graphs correctly represent the relationship between pressure P and volume V for an ideal gas when the temperature of the gas and the mole of the gas remain constant?
|
||||||||||||||||||||||
|
||||||||||||||||||||||
Question 1:
Analysis of each option:
A. Using sandpaper to remove the layer of magnesium oxide on the surface of the magnesium ribbon before heating.
Correct. Magnesium ribbon naturally has a coating of magnesium oxide (due to reaction with air). If this coating is not removed, the initial mass recorded includes oxygen that was already present before the reaction. This means the mass of magnesium that actually reacts is lower than recorded, and the calculated mass of oxygen gained will also be incorrect. This introduces a systematic error. Removing the coating addresses this procedural flaw directly.
This increases the size of the sample, which may reduce the percentage error from the balance, but it does not correct the underlying procedural flaw (like the oxide coating or incomplete reaction).
This reduces the effect of random errors and improves precision, but it does not eliminate systematic errors. If the same flawed method is repeated, the average will still be incorrect.
Therefore, the best way to reduce the systematic error is to ensure that the magnesium is clean and free of its oxide coating before the initial weighing.
Answer: A
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 2:
Answer: B
Explanation
This question asks which option contributes to random errors in the experiment. Random errors are unpredictable fluctuations in measured quantities that affect the precision of the results. They can be reduced by repeating the experiment and taking an average.
Analysis of each option:
A. The use of a glass beaker which does not conduct heat well.
This is a systematic error. The poor heat conduction consistently prevents all the heat from the flame from being transferred to the water, causing the measured temperature rise (and therefore the calculated enthalpy change) to be consistently too low.
This contributes to random error. The limitation of the balance's precision (rounding to 0.1 g) introduces uncertainty in the mass readings. Each reading could be up to ±0.05 g from the true value. This uncertainty is random and affects the precision of the final result.
This is a systematic error. If alcohol evaporates from the wick or burner between initial and final weighings, the mass loss recorded will be greater than the mass actually burned to heat the water. This consistently leads to an overestimation of the fuel used and an underestimation of the enthalpy change (less negative).
This is a systematic error. Heat consistently escapes from the beaker and the flame to the surroundings instead of going into the water. This causes the measured temperature rise to be consistently lower than it would be under perfect conditions.
Therefore, only the limited precision of the balance (Option B) introduces a random error.
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 3:
Explanation
To answer this question, it is essential to understand the definitions of accuracy and precision:
Accuracy refers to how close a measured value is to the true or accepted value (in this case, the literature value of 1.10 V).
Precision refers to how close the repeated measurements are to each other (how consistent/reproducible the results are).
Analysis of the data:
The experimental results obtained were: 1.37 V, 1.39 V, and 1.38 V.
Precision:
The values are all very close to each other (ranging from 1.37 V to 1.39 V).
This indicates high consistency and reproducibility.
Therefore, the results are precise.
The average of the results is approximately 1.38 V.
The true (literature) value is 1.10 V.
The experimental values are significantly higher (an error of about +0.28 V).
Therefore, the results are not accurate.
Since the results are consistent with each other (precise) but far from the true value (not accurate), the correct description is precise but not accurate.
Answer: C
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 4:
Answer: B
Explanation
The percentage error is calculated by comparing the experimental value to the accepted (literature) value. The formula is:
Percentage Error= (Accepted Value−Experimental Value) / Accepted Value×100%Step 1: Identify the values
Accepted (Literature) Value = +70.0 kJ mol−1
Experimental Value = +45.7 kJ mol−1
Step 2: Calculate the absolute error
Absolute Error=∣70.0−45.7∣=24.3 kJ mol−1Step 3: Calculate the percentage error
Percentage Error=24.3/70.0×100%
Percentage Error=0.34714...×100%=34.7%
Therefore, the percentage error in this experiment is 34.7%.
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 5:
Answer: C
Explanation
To answer this question correctly, it is important to distinguish between the definitions and causes of random errors and systematic errors, and to understand how they relate to accuracy and precision.
Random errors cause unpredictable fluctuations in measurements, leading to a lack of precision (spread of results). They can be reduced by repeating experiments and averaging, or by using more precise instruments, but they cannot be completely eliminated.
Systematic errors cause measurements to be consistently shifted in one direction, leading to a lack of accuracy (closeness to the true value). They are often due to flawed apparatus or experimental design.
Analysis of each option:
A. The random error in measuring temperature can be eliminated by using a more precise temperature probe, which measures to 2 decimal places.
Incorrect. Using a more precise instrument reduces the magnitude of random error (by allowing smaller increments to be read), but it does not eliminate it. There will always be some degree of uncertainty in any measurement. Random error cannot be eliminated entirely.
Incorrect. Using a more precise balance reduces random error in the mass measurement. It does not address a systematic error. Systematic errors (e.g., heat loss to the surroundings, an impure sample) are flaws in the experimental setup or procedure and are not fixed by using a more precise instrument.
Correct. This is the fundamental definition of random error. Random errors cause the results to be scattered around a mean value; the greater the random error, the lower the precision of the data set.
Incorrect. A lack of repeats is not an error itself; it is a failure to address random errors. Repeating an experiment helps to identify and reduce the effect of random errors (by allowing an average to be calculated). The absence of repeats does not cause a systematic shift in the data.
Therefore, the correct statement is that random errors lead to imprecision in the results.
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 6:
Explanation
To identify the correct classification of variables, it is important to understand the definitions in the context of an experiment:
Independent Variable: The variable that is deliberately changed or selected by the investigator.
Dependent Variable: The variable that is measured as the outcome; it changes in response to the independent variable.
Controlled Variable: A variable that is kept constant throughout the experiment to ensure a fair test.
Step-by-step analysis of the experiment:
The aim of the investigation is: "to study the effect of concentration of the reactant on the rate of hydrogen peroxide decomposition."
Independent Variable:
The experiment is investigating the effect of concentration. Therefore, the concentration of H2O2 is the factor that is deliberately changed by the experimenter.
Independent Variable = Concentration of H2O2.
The dependent variable is what is measured to see the effect of the change in concentration. The rate of reaction can be measured by monitoring a product. For this reaction, the volume of oxygen gas (O2) given off in a period of time is a direct measure of the reaction rate.
Dependent Variable = Volume of O2 given off in a period of time.
To ensure that any change in the rate is solely due to the change in concentration, all other factors that could affect the rate must be kept constant. A key factor that affects reaction rates is temperature.
Controlled Variable = Temperature of the reaction mixture.
Matching to the table:
This classification matches option D exactly.
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 7:
The titre = final reading – initial reading.
We are told the smallest division on the burette is 0.1 cm³, so the uncertainty in each reading is ±0.05 cm³ (half the smallest division, assuming typical lab practice).
For trial 2:
Initial burette reading = 12.20 cm³
Final burette reading = 37.30 cm³
Uncertainty in initial reading = ±0.05 cm³
Uncertainty in final reading = ±0.05 cm³
When subtracting, absolute uncertainties add:
Absolute uncertainty=0.05+0.05=0.10 cm3Percentage uncertainty=0.10/25.10×100%
0.10/25.10≈0.003984 (4 sig. figs from 25.10)
0.003984×100≈0.3984%
Rounded to 3 significant figures: 0.398%
0.398% corresponds to option C.
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 8:
Step 1: Titre values
Trial 1: 25.00 cm3
Trial 2: 25.10 cm3
Trial 3: 25.20 cm3
Step 2: Mean
(25.00+25.10+25.20)/3=75.30/3=25.10 cm3Step 3: Half the range
Range =25.20−25.00=0.20 cm3
Half the range =0.10 cm3
This ±0.10 cm³ is the absolute uncertainty, although it is standard practice to give this as one significant figure as it is an estimate of the error.
Final error should be given as ±0.1 cm³, and therefore the final answer to the same number of decimal places (25.1) cm³
Step 4: Final expression
25.1±0.1 cm³That's option B
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 9:
We can break this down by recalling how uncertainties propagate in multiplication/division.
For multiplication or division:
Percentage uncertainty in the result = sum of percentage uncertainties in each factor.
A: "Absolute uncertainty … is equal to the sum of the percentage uncertainties" — No, absolute uncertainties don’t add like that; percentage ones do in multiplication/division.
B: "Percentage uncertainty … is equal to the sum of the percentage uncertainties in the volume of NaHCO₃ and in the volume of the acid titre" — Yes, this matches the rule.
C: "Absolute uncertainty … is equal to the product of the percentage uncertainties" — No, nonsense.
D: "Percentage uncertainty … is equal to the product …" — No, it’s sum, not product.
*These A.I. responses have been individually checked to ensure they match the accepted answer, but explanations may still be incorrect. Responses may give guidance but the A.I. might not be able to answer the question! This is particularly the case for questions based on diagrams, which the A.I. typically cannot interpret.
Grade Gorilla uses Gemini, Deepseek and a range of other A.I. chatbots to generate the saved responses. Some answers have had human intervention for clarity or where the A.I. has not been able to answer the question.
Question 10:
According to the ideal gas law, PV=nRT, where P is pressure, V is volume, n is the number of moles, R is the ideal gas constant, and T is the absolute temperature. The problem states that n and T are constant, so the product PV is constant. This relationship is known as Boyle's Law.
Graph I: The relationship P∝V shown is incorrect. This would imply PV is not constant.
Graph II: The relationship P∝1V shown is correct. This means that as volume increases, pressure decreases proportionally, keeping the product PV constant.
Graph III: The graph shows that the product PV is constant regardless of the volume V, which is correct for an ideal gas at constant temperature.
Therefore, only graphs II and III correctly represent the relationship.
This matches option C.
